| X travel |
1,200 mm |
|---|---|
| Y travel |
610 mm |
| Z travel |
610 mm |
| Spindle nose to table surface |
150 ~ 760 mm |
|
Table size |
1,300 x 600 mm |
|
T-slot (Q'ty x Size x Dist) |
5 x 18 x 100 mm |
| Max. Table Load | 1,200 kgs |
| CNC Control | Mitsubishi / Fanuc / Siemens / Heidenhain / Fagor |
|
Spindle |
|
|---|---|
|
Spindle Transmission |
Belt type |
|
Spindle Taper |
BT40 |
| Spindle Speed |
8,000 rpm |
| Spindle motor |
7.5 / 11 kW (*) |
|
Other items |
|
|---|---|
|
ATC Capacity |
ATC Genoa type 20 tools / Arm type 24 tools |
* Light bar type machine: optional guarding.
* Spindle motor power depends on motor selection.
*Note: Specifications are subject to change without further notice.
